Your door: 8' x 7' · Almond · Flush · Insulated Long · Left Side · Clear
Garage Doors
Amarr Lincoln 3138 (Insulated R-6.48) Steel Garage Door
Amarr Lincoln 3138 (LI3138) — a 1-3/8" triple-layer insulated steel garage door (R-6.48) with modern flush, ribbed, and SlimLine options. Sold and installed by Modern Decor Supply across New Jersey and the surrounding region.
Frames match the door unless you choose black. No price change.
Included — inserts don't change the price.
How to measure
Headroom is the space between the top of the finished opening and the ceiling — or, if something hangs lower, the space to that: a pipe, a beam, a light, the opener rail. Measure at the tightest point across the whole opening.
Two more numbers help us confirm the fit: side room, from each side of the opening to the wall (about 5″ each side for a standard track), and backroom, the depth straight back into the garage (your door height plus about 18″).
Enter your headroom to see which tracks fit.
Financing available through Synchrony Bank · Promotional/sale-priced items are not eligible for financing. Learn more →
Prefer Amarr's own designer? Open the Amarr door builder
- Construction: triple-layer steel-insulation-steel, 1-3/8" thick, 27/27-gauge
- Insulation: R-6.48 / U-factor 0.27
- Panel designs: modern Flush & Ribbed plus traditional Short & Long
- Colors: 10 finishes plus 900+ Amarr Color Zone custom colors
- Windows: Clear, Obscure, Frost & Dark Tint glass (single-pane or insulated); DecraTrim, DecraGlass, modern SlimLine & Mosaic window options
The Lincoln collection runs from a single-layer steel door to a fully insulated triple-layer build, in four panel designs and ten finishes. Every Lincoln we sell is measured, supplied and installed by our own team across North Jersey and the tri-state area.
Construction
LI1000
Single-layer steel
Heavy-duty exterior steel with a woodgrain emboss. The straightforward choice for a detached or unconditioned garage where insulation isn't the priority.
- Heavy-duty exterior steel
- Durable, low maintenance
- No insulation
LI2000
Steel + insulation
Adds polystyrene insulation with a vinyl backing — noticeably quieter in operation and a sensible step up for a garage that shares a wall with living space.
- Heavy-duty exterior steel
- Polystyrene insulation, vinyl-backed
- Quieter operation
LI3138
Steel + insulation + steel
A true triple-layer door at 1-3/8" thick, with steel on both faces so the inside looks as finished as the outside.
- Steel inside and out
- Polystyrene insulation
- Extra quiet operation
LI3000
Steel + insulation + steel
The best-insulating door in the Lincoln line at 2" thick — the one to choose for an attached garage in a North Jersey winter, or any garage you actually spend time in.
- Steel inside and out
- Highest R-value in the line
- Extra quiet operation
Specifications
| Specification | LI1000 | LI2000 | LI3138 | LI3000 |
|---|---|---|---|---|
| Panel designs | Short · Long · Flush | Short · Long · Flush | Short · Long · Flush · Ribbed | Short · Long · Flush · Ribbed |
| Steel embossment | Woodgrain* | Woodgrain* | Woodgrain | Woodgrain |
| Insulation | — | Polystyrene | Polystyrene | Polystyrene |
| U-factor | — | 0.32 | 0.27 | 0.23 |
| R-value | — | 6.64 | 6.48 | 9.05 |
| Door thickness | 2" (5.1 cm) | 2" (5.1 cm) | 1-3/8" (3.5 cm) | 2" (5.1 cm) |
| Steel thickness | 25 ga | 25 ga | 27/27 ga | 27/27 ga |
| Insulated glass option | — | — | Available | Available |
| Wind load available | Yes | Yes | Yes | Yes |
U-factor and R-value are verified under the DASMA Thermal Performance Verification Program — a lower U-factor means better thermal performance. Insulation has passed self-ignition, flamespread and smoke-developed index fire testing. Confirming that a door meets local building codes is the homeowner's responsibility; we're happy to advise on North Jersey requirements.
Finishes
Ten factory finishes, including two dual-directional woodgrains. Woodgrain finishes are available across all panel designs. Any Lincoln finish can be matched to our European entry doors and windows — the reason most of our customers end up choosing one.
- True White TW
- Almond AL
- Wicker Tan WK
- Sandtone ST
- Terratone TT
- Dark Brown DN
- Charcoal Gray EF
- Black BL
- Walnut NT
- Mahogany MY
A price upcharge applies to all colors except True White. Flush panels in LI1000/LI2000 carry a stucco texture rather than woodgrain. Over 900 Sherwin-Williams SnapDry colors are available through the Amarr Color Zone program — ask us.
Glass and windows
| Glass | Notes |
|---|---|
| Clear | 3/32" (0.24 cm) single strength |
| Obscure | Price upcharge applies |
| Frost | Price upcharge applies |
| Dark Tint | Price upcharge applies |
Insulated glass is available in Clear, Frost and Dark Tint on LI3138 and LI3000. SlimLine windows — the same width as a standard long-panel window and half the height — come in black or white frame only, on LI3138 and LI3000 flush and ribbed panels.
Window inserts
DecraTrim inserts add a grille pattern over your chosen glass. Available designs depend on panel style:
Short panel
- Stockton (20)
- Prairie (21)
- Cathedral (22)
- Cascade (23)
- Waterford (25)
- Wagon Wheel (26)
- Sunray (27)
- Full Sunray (28)
- Five Piece Sunray (29)
Long panel
- Stockton (20)
- Prairie (21)
- Cathedral (22)
- Cascade (23)
- Moonlite (24)
- Waterford (25)
- Wagon Wheel (26)
- Sunray (27)
- Thames (30)
- Arched Thames (31)
- Full Sunray (28)
Full Sunray (28) is available on 16', 17' and 18' doors for short panel, and 15'6", 15'8", 16', 17' and 18' for long panel. Five Piece Sunray (29) is available on 10' doors in True White only.
DecraGlass replaces the glass with tempered obscure glass carrying a baked-on ceramic design. Design visibility varies with lighting.
- Heartland (70)
- Mission (71)
- Jardin (75)
- Trellis (76)
- Victorian (54)
Amarr door specifications and technical data are subject to change without notice.
Below are specifications of all Garage Door Motor Options
LM L979M WIRELESS KEYPAD MAX:
- Compatible with most major brands of Garage Door Openers manufactured after January 1997.
- Easier programming with automatic frequency detection.
- Program in myQ app and access features (PIN codes, set schedules, notifications, access history and battery status) with Security+ 3.0 Garage Door Openers.
- Users can program temporary PIN codes for friends and service people.
- Closes the Garage Door instantly with one press activation
LM 878 Max Wireless Keypad
- Features Security+ 2.0® rolling code technology
- One-button-to-close feature (works with all LiftMaster garage door openers manufactured since 2006)
- Temporary password option, Program code directly from keypad
- Backlit keypad, Includes 9V battery
- Compatible with all LiftMaster garage door openers manufactured since January 1993
KSWKP WIRELESS KEYPAD KWIKSET
- Compatible with Kwikset FLEX openers
- Open or close the garage door without using a remote
- Includes 9V battery
LM 893 Max 3-Button Remote Control
- Controls up to three garage door openers, gates or myQ® enabled light devices
- Features Security+2.0 rolling code technology
- Compatible with all LiftMaster garage door openers manufactured since January 1993, and all 315MHz LiftMaster and ELITE gate operators
LM L932M 2 BUTTON KEYCHAIN MAX
- Compatible with up to three Garage Door Openers, Gate Operators, or Commercial Door Operators manufactured by LiftMaster after 1997.
- Extra-long range for extended reach and reliable operation.
- Easier programming with automatic frequency detection.
- Program in myQ app and access features (naming, notifications and access history) with Security+ 3.0 and Security+ 2.0 Garage Door Openers.
- Fits on a keychain, backpack or in a purse or pocket
KSTX3 FLEX REMOTE 3 BUTTON
- Compatible with Kwikset FLEX openers
- Controls up to three Garage doors
- Flexible to use as visor mount or keychain remote
- HomeLink compatible
- 315MHz frequency
- Powered by 2032 coin cell battery (included)
KSTX1 FLEX REMOTE 1 BUTTON
- Compatible with Kwikset FLEX openers
- Controls one garage door
- Flexible to use as visor mount or keychain remote
- HomeLink compatible
- 315MHz frequency
- Powered by 2032 coin cell battery (included)
